GZPW Reference 250

25 cm / 10″ high end subwoofer

SKU: 51620010 Categories: , ,

Description

25 cm / 10″ high end subwoofer

500 Watts RMS

10″ high end sound quality subwoofer with aluminum cast basket and coated paper cone

  • 10″ high end subwoofer
  • Klippel® optimized
  • 3-layer sandwich cone
  • Leightweight rubber surround
  • Solid aluminum cast basket
  • 50 mm / 2″ copper voice coil
  • 2-layer Bimax spider
  • Coated paper dust cap

Additional information

Model

High-End SQ Subwoofer

Diameter

25 cm / 10"

Power handling (RMS)

500 Watts

Impedance

2x 2 Ohms

Efficiency

86,0 dB

Power recommendation

300 – 600 Watts

Voice coil

50 mm / 2" copper

Cone

3-layer sandwich

Max. Excursion (Xmax)

40 mm

Mounting depth

128 mm

Resonance frequency (Fs)

26.1 Hz

Damping ratio (Qts)

0.34

Equiv. air volume (Vas)

36.5 L / 1.29 cu.ft.

Downloads

Owner’s Manual
