GZCM 6.5N-PROC
165 mm / 6.5″ high power midrange speaker with neodymium motor
400 Watts max
165 mm / 6.5″ high end SPL midrange speaker with neodymium motor and aluminum cast basket
- 6.5″ high power midrange speaker with neodymium motor
- 38 mm / 1.5″ CCA voice coil
- Carbon cone
- Neodymium motor
- Aluminum cast housing
- Push terminal
- 1 piece / package
| Model | High end midrange speaker with neodymium magnet |
|---|---|
| Diameter | 165 mm / 6.5″ |
| Power handling (RMS/max.) | 200 / 400 Watts |
| Impedance | 4 Ohm |
| Efficiency | 94 dB |
| Frequency response | 150 Hz – 12 kHz |
| Voice coil | 38 mm / 1.5″ CCA |
| Cone | carbon fiber |
| Mounting Ø | 147 mm / 5.79″ |
| Mounting depth | 63 mm / 2.48″ |
| Resonance frequency (Fs) | 125 Hz |
| Damping ratio (Qts) | 0.45 |
| Equiv. air volume (Vas) | 4 L / 0.14 cu.ft. |
