GZHW 16-D2
16 cm High-Performance Subwoofer
1000 Watts SPL
6.3″ High-Performance Subwoofer with alumiunum cast basket and reinforced paper cone
- 6.3″ high quality SPL subwoofer
- Klippel® optimized
- Reinforced paper cone
- Long stroke compound surround
- Solid aluminum cast basket
- 50 mm / 2″ copper voice coil
- 2-layer Polycot spider
- Carbon dust cap
| Model | High-Performance Subwoofer |
|---|---|
| Diameter | 16 cm / 6.3” |
| Power handling (RMS/SPL) | 500 / 1000 Watt |
| Impedance | 2x 2 Ohms |
| Efficiency | 81 dB |
| Power recommendation | 400 – 1000 Watt |
| Voice coil | 50 mm / 2” copper |
| Cone | Reinforced paper |
| Max. Excursion (Xmax)) | 30 mm / 1.18” |
| Mounting cut out Ø | 153 mm / 6.02” |
| Mounting depth | 110 mm / 4.33” |
| Resonance frequency (Fs) | 51 Hz |
| Damping ratio (Qts) | 0.46 |
| Equiv. air volume (Vas) | 2.8 L / 0.10 cu.ft. |
