Magnifier
GZPC 50Y-OFC
50 mm² OFC power wire – yellow
50 mm² OFC power wire – yellow
Power wire
50 mm² OFC power wire – yellow / roll
- Highly flexible power cable
- 20 m / 65.62 ft
- Yellow jacket
- Wooden spool
Magnifier
GZPC 50B-OFC
50 mm² OFC power wire – black
50 mm² OFC power wire – black
Power wire
50 mm² OFC power wire – black / roll
- Highly flexible power cable
- 20 m / 65.62 ft
- Black jacket
- Wooden spool
Magnifier
GZPC 35B-OFC
35 mm² OFC power wire – black
35 mm² OFC power wire – black
Power wire
35 mm² OFC power wire – black / roll
- Highly flexible power cable
- 30 m / 98.43 ft
- Black jacket
- Wooden spool
Magnifier
GZPC 35Y-OFC
35 mm² OFC power wire – yellow
35 mm² OFC power wire – yellow
Power wire
35 mm² OFC power wire – yellow / roll
- Highly flexible power cable
- 30 m / 98.43 ft
- Yellow jacket
- Wooden spool
Magnifier
GZPC 20B-OFC
20 mm² OFC power wire – black
20 mm² OFC power wire – black
Power wire
20 mm² OFC power wire – black / roll
- Highly flexible power cable
- 50 m / 164.04 ft
- Black jacket
- Wooden spool
Magnifier
GZPC 20Y-OFC
20 mm² OFC power wire – yellow
20 mm² OFC power wire – yellow
Power wire
20 mm² OFC power wire – yellow / roll
- Highly flexible power cable
- 50 m / 164.04 ft
- Yellow jacket
- Wooden spool
Magnifier
GZPC 10Y-OFC
10 mm² OFC power wire – yellow
10 mm² OFC power wire – yellow
Power wire
10 mm² OFC power wire – yellow / roll
- Highly flexible power cable
- 50 m / 164.04 ft
- Yellow jacket
- Wooden spool
Magnifier
GZPC 10B-OFC
10 mm² OFC power wire – black
10 mm² OFC power wire – black
Power wire
10 mm² OFC power wire – black / roll
- Highly flexible power cable
- 50 m / 164.04 ft
- Black jacket
- Wooden spool
Magnifier
GZCS 100.2MB-206C
Car specific 100 mm / 4″ 2-way speaker system
Car specific 100 mm / 4″ 2-way speaker system
Plug´n´play installation
Car specific 100 mm / 4″ 2-way speaker system for Mercedes
- 2-way speaker for Mercedes
- Suitable for various vehicles
- Glas fiber cone
- neodymium motor
- 25 mm / 1″ silk dome tweeter
- Car specific connection
- 1 pair / package
| Model | Car specific 2-way speakers |
|---|---|
| Diameter | 100 mm / 4″ |
| Power handling (RMS/max.) | 60 / 100 Watts |
| Impedance | 4 Ohms |
| Efficiency | 85 dB |
| Frequency Response | 100 Hz – 24 kHz |
| Voice coil | 25 mm / 1″ copper |
| Midwoofer | Glass fiber cone |
Magnifier
GZCS F-4.0X
Car specific 100 mm / 4″ 2-way coaxial speaker system
Car specific 100 mm / 4″ 2-way coaxial speaker system
Plug´n´play installation
Car specific 100 mm / 4″ 2-way coaxial speaker system
- 2-way center coax-speaker for BMW and Mercedes
- Suitable for various vehicles
- Glas fiber cone
- neodymium motor
- GZ design aluminum cast basket
- GZ design aluminum mounting frame for BMW
- Aluminum adaptor-bolts for MERCEDES
- 20 mm / 0.79″ silk dome tweeter
- Car specific connection
- 1 pair / package
| Model | Car specific 2-way coax-speaker |
|---|---|
| Diameter | 100 mm / 4″ |
| Power handling (RMS/max.) | 60 / 100 Watts |
| Impedance | 4 Ohms |
| Efficiency | 87 dB |
| Frequency Response | 70 Hz – 22 kHz |
| Voice coil | 25 mm / 1″ copper |
Magnifier
GZCA 13000.M1
Mono competition SPL amplifier
Mono competition SPL amplifier
High-power mono class D amplifier
1-channel 1-ohm stable SPL high power amplifier with class D circuit, integrated active crossover and bass boost
- SPL high power amplifier
- High-efficient class D technology
- Variable active crossover and bass boost
- Particularly qualified for SPL and SQL applications
- Stabilized high voltage power supply
- Large terminals
- Flat heatsink design in classic GZ style
- Wired bass level remote control included
| Model | Competition SPL amplifier |
|---|---|
| Channels | 1 |
| Output Power (@ 4Ω) | 3200 Watts RMS |
| Output Power (@ 2Ω) | 6400 Watts RMS |
| Output Power (@ 1Ω) | 12560 Watts RMS / 14800 Watts max |
| Frequency Response | 15 Hz – 200 Hz |
| HPF / LPF / BPF | ● / ● / ● |
| Bass Boost / Phase switch | ● / ○ |
| High level input / Auto-on | ○ / ○ |
| Remote | ● |
| BIAS Setting | ○ |
| Linkmode | ○ |
| Dimensions (W x L x H) | 200 x 455 x 57 mm / 7.87″ x 17.91″ x 2.24″ |
Magnifier
GZCA 3000X.M1
Mono competition SPL amplifier
Mono competition SPL amplifier
High-power class D amplifier
1-channel 1-ohm stable SPL high power amplifier with class D circuit, integrated active crossover and bass boost
- SPL high power amplifier
- High-efficient class D technology
- Variable active crossover and bass boost
- Particularly qualified for SPL and SQL applications
- Stabilized high voltage power supply
- Large terminals
- Flat heatsink design in classic GZ style
- Wired bass level remote control included
| Model | Competition SPL amplifier |
|---|---|
| Channels | 1 |
| Output Power (@ 4Ω) | 1000 Watts RMS |
| Output Power (@ 2Ω) | 1825 Watts RMS |
| Output Power (@ 1Ω) | 3180 Watts RMS / 4500 Watts max |
| Frequency Response | 10 Hz – 200 kHz |
| HPF / LPF / BPF | ● / ● / ● |
| Bass Boost / Phase switch | ● / ○ |
| High level input / Auto-on | ○ / ○ |
| Remote | ● |
| BIAS Setting | ○ |
| Linkmode | ○ |
| Dimensions (W x L x H) | 265 x 150 x 58 mm / 10.43″ x 5.91″ x 2.28″ |
Magnifier
GZRW 8XSPL-D1
20 cm / 8″ high quality SPL subwoofer
20 cm / 8″ high quality SPL subwoofer
1000 Watts SPL
8″ high quality SPL subwoofer with reinforced paper cone, 2×1 ohm
- 8″ high quality SPL subwoofer
- Klippel® optimized
- Reinforced paper cone
- Long stroke compound surround
- Resonance free steel basket
- 50 mm / 2″ copper voice coil
- Polycot spider
- IMPP dust cap with 3D structure logo
| Model | High-Quality SPL subwoofer |
|---|---|
| Diameter | 20 cm / 8″ |
| Power handling (RMS/SPL) | 500 / 1000 Watts |
| Impedance | 2x 2 Ohms |
| Efficiency | 84.6 dB |
| Power recommendation | 400 – 1000 Watts |
| Voice coil | 50 mm / 2″ copper |
| Cone | Reinforced paper |
| Max. Excursion (Xmax) | 22 mm / 0.866″ |
| Mounting Ø | 182 mm / 7.17″ |
| Mounting depth | 133 mm / 5.24″ |
| Resonance frequency (Fs) | 45.8 Hz |
| Overall quality (Qts) | 0.36 |
| Equiv. air volume (Vas) | 7.4 L / 0.26 cu.ft. |
Magnifier
GZHW 16-D2
16 cm High-Performance Subwoofer
1000 Watt SPL
High power 6.3” High-Performance Subwoofer
- Efficient double magnet
- Klippel® optimized
- Massive aluminum cast basket
- Reinforced paper cone
- Carbon dust cap
- 2” copper voice coil
- High-roll U-surround
- Speaker wire connection
| Model | High-Performance Subwoofer |
|---|---|
| Diameter | 16 cm / 6.3” |
| Power handling (RMS/SPL) | 500 / 1000 Watt |
| Impedance | 2x 2 Ohms |
| Efficiency | 81 dB |
| Power recommendation | 400 – 1000 Watt |
| Voice coil | 50 mm / 2” copper |
| Cone | Reinforced paper |
| Max. Excursion (Xmax)) | 30 mm / 1.18” |
| Mounting cut out Ø | 153 mm / 6.02” |
| Mounting depth | 110 mm / 4.33” |
| Resonance frequency (Fs) | 51 Hz |
| Damping ratio (Qts) | 0.46 |
| Equiv. air volume (Vas) | 2.8 L / 0.10 cu.ft. |
Magnifier
GZREM 1-A
Optional bass remote control
Small profile cable remote
Remote control for COMPETITION series amplifiers
- compatible with GZCA 3000X.M1/M2, GZCA 3000.M1-24V, GZCA 5000X.M1/M2, GZCA 8000.M1, GZCA 13000.M1, GZCA 300.Q1, GZCA 300.4-1Ohm
- Including connection wire 500 cm
- Control function: main level
| Type | Wired remote Control |
|---|---|
| Housing | Black |
Magnifier
GZRB 20SPL-ACT
20 cm / 8″ Active vented SPL subwoofer enclosure
Active SPL subwoofer
Active vented enclosure including 8″ RADIOACTIVE SPL subwoofer
- 280/330 Watts amplifier
- Airflow optimised ventilation
- Wooden enclosure
- High level input
- Automatic turn-on function
- Low pass filter
- Phase correction
- Preset Subsonic (20 Hz)
- Remote-out
- Bass level remote control included
| Type | Active Subwoofer Box |
|---|---|
| Diameter | 20 cm / 8″ |
| Amplifier power (RMS/max.) | 280 / 330 Watt |
| Impedance | 2 Ohms |
| Net Volume | 21 L / 0.74 cu.ft. |
| Subwoofer | GZRW 8XSPL-D1 |
| Amplifier modul | GZ SUB-AMP 300 |
| Dimensions (w x h x d) | 440 x 240 x 280 mm / 17.32″ x 9.45″ x 11.02″ |
Magnifier
GZPW 15C
38 cm / 15″ high power subwoofer
6500 Watts RMS
15″ high power subwoofer with airflow optimized aluminum cast basket
- 15″ high power subwoofer
- Klippel® optimized
- Carbon-fiber cone
- Airflow optimized aluminum cast basket
- 100 mm / 4″, 4-layer flat wire CCA voice coil
- 7-layer 12” spider
- Carbon fiber dust cap
| Type | High-Power Subwoofer |
|---|---|
| Diameter | 38 cm / 15″ |
| Power handling (RMS) | 6500 Watts |
| Impedance | 2x 1 Ohm |
| Efficiency | 86 dB |
| Power recommendation | 4500 – 6500 Watts |
| Voice coil | 100 mm / 4″ CCA |
| Cone | Carbon-fiber |
| Max. excursion (Xmax) | 60 mm / 2.36″ |
| Mounting Ø | 360 mm / 14.17″ |
| Mounting depth | 300 mm / 11.8″ |
| Resonance frequency (Fs) | 31 Hz |
| Damping ratio (Qts) | 0.51 |
| Equiv. air volume (Vas) | 28.18 L / 0.995 cu.ft. |
Magnifier
GZNW 38C
38 cm / 15″ high performance subwoofer
6000 Watts
15″ high performance subwoofer with airflow optimized aluminum cast basket
- 15″ high performance subwoofer
- Klippel® optimized
- Carbon-fiber cone
- Airflow optimized aluminum cast basket
- 75 mm / 3″, 8-layer flat wire CCA voice coil
- 7-layer 12” spider
- Carbon-fiber dust cap
- Massive push terminals
| Type | High-Performance SPL Subwoofer |
|---|---|
| Diameter | 38 cm / 15″ |
| Power handling (RMS/SPL) | 6000 / 25000* Watts |
| Impedance | 2x 1 Ohm |
| Efficiency | 86 dB |
| Power recommendation | 3000 – 6000 Watts |
| Voice coil | 75 mm / 3″ CCA |
| Cone | Carbon-fiber |
| Max. excursion (Xmax) | 80 mm / 3.15″ |
| Mounting Ø | 360 mm / 14.17″ |
| Mounting depth | 290 mm / 11.42″ |
| Resonance frequency (Fs) | 33 Hz |
| Damping ratio (Qts) | 0.38 |
| Equiv. air volume (Vas) | 23 L / 0.81 cu.ft. |
Magnifier
GZ BASS KIT 12.300X-II CONNECT
30 cm / 12″ vented subwoofer loaded enclosure with separate amplifier
Subwoofer package with 300 Watts amplifier
Vented enclosure with 30 cm / 12″ subwoofer and front bass vent, red logo stitch and side panels, bridgeable 2-channel amplifier
- Subwoofer kit with amplifier
- 12″ subwoofer with IMPP cone
- Vented enclosure with front aero-port
- 1.41 ft³ net volume
- Mono class AB amplifier
- 300 Watts max output power
- Variable active crossover + Bass Boost
- High-level input with auto-on function
- Including cable kit
- Wired bass level remote control optionally available (usable in LPF mode)
| Model | Subwoofer kit incl. 2-channel amplifier |
|---|---|
| Amplifier | GZBA 1.300X |
| Amplifier Power (RMS/max.) | 200 / 300 Watts |
| Low Pass Filter | 40 – 250 Hz |
| Bass Boost | 0 – 6 dB (40 Hz) |
| Amplifier Frequency Response | 15 Hz – 20 kHz |
| Input Sensitivity | 200 mV – 6.5 V |
| High Pass Input | Yes |
| Auto-on Function | Yes |
| Dimensions | 180 x 236 x 53 mm / 7.09″ x 9.29″ x 2.09″ |
| Impedance Subwoofer | 4 ohms |
| Net Box Volume | 40 L / 1.41 cu.ft. |
| Box Dimensions | 560 x 360 x 350/250 mm / 22.05″ x 14.17″ x 13.78″/9.84″ |
Magnifier
GZIA 1500.1
1-channel high quality class D amplifier
Powerful class D amplifier
1-channel subwoofer amplifier with class D circuit, integrated active crossover and regulated power supply
- Mono amplifier
- 1 ohm stable
- Class D technology
- Variable active crossover and bass boost
- High-level input with auto-on function & dummy load
- GZ-PowerBalance power supply regulation
- Large terminals
- Black anodized heatsink with Ground Zero lettering
- Bass remote control included
- Triple protection circuit
| Model | High quality class D amplifier |
|---|---|
| Channels | 1 |
| Output Power (@ 4Ω) | 430 Watts RMS |
| Output Power (@ 2Ω) | 850 Watts RMS |
| Output Power (@ 1Ω) | 1530 Watts RMS |
| max. Output Power (CEA-2006A / 10%THD+N) | 1900 Watts |
| Frequency Response | 10 – 250 Hz |
| HPF / LPF / BPF | ● / ● / ● |
| Bass Boost / Phase switch | ● / ○ |
| High level input / Auto-on | ● / ● |
| Remote | ● |
| BIAS Setting | ○ |
| Linkmode | ○ |
| Dimensions (W x L x H) | 168 x 49 x 295 mm / 6.61″ x 1.93″ x 11.61″ |
