GZPW 15NEO-XSPL
38 cm / 15″ high power SPL subwoofer with neodymium motor
25000* Watts SPL
15″ high power SPL subwoofer with airflow optimized aluminum cast basket
- 15″ high power SPL subwoofer
- Klippel® optimized
- Carbon-fiber cone
- Multi-piece neodymium motor
- Airflow optimized aluminum cast basket
- 100 mm / 4″, 8-layer flat wire CCA voice coil
- 7-layer 12” spider
- Carbon fiber dust cap
- Fixed connection cables
- *for 3 sec.
| Type | Neodymium SPL Subwoofer |
|---|---|
| Diameter | 38 cm / 15″ |
| Power handling (RMS/SPL) | 6500 / 25000 Watts |
| Impedance | 2x 1 Ohm |
| Efficiency | 90 dB |
| Power recommendation | 4500 – 6500 Watts |
| Voice coil | 100 mm / 4″ aluminium |
| Cone | Carbon |
| Max. excursion (Xmax) | 60 mm / 2.36″ |
| Mounting Ø | 360 mm / 14.17″ |
| Mounting depth | 325 mm / 12.8″ |
| Resonance frequency (Fs) | 41.2 Hz |
| Dämpfungsgrad (Qts) | 0.19 |
| Damping ratio (Qts) | 25.6 L / 0.90 cu.ft. |
